The step feeder is designed for the feeding and orientation of components from a random bulk source. The M/c comes complete with integral storage, feed track and control ensuring an accurate interface of the relative modules and ease of installation.
Movement of the parts from the random storage area is by reciprocating plates picking up parts on the leading edge of one plate and transferring to the leading edge of the next etc. until the desired discharge height is reached for presentation to the orientation tooling.
The plates are driven by a motor through a gearbox reduction to the desired reciprocating speed and come in different widths and depths to suit the component being handled and feed rate requirement.
The smooth reciprocating action of the stepper plates ensures a positive, quiet and gentle movement of the components. Wear is negligible in the absence of a constant churning and tumbling action.
The feeder is not weight sensitive, whether full or near empty feed rates remain constant.
The orientation tooling is manufactured in-line allowing easy replacement inter-changeability or adjustment as necessary and is mounted on either a pneumatic or electro-magnetic linear driver.
Surplus parts from the orientation tooling are either re-circulated through the tooling if particularly sensitive or returned to the storage facility.
Sensors control the level within the orientation track, re-cycling facility, operation of the stepper plates and storage conveyor if fitted. |
